Product description
The drive shaft crossmember is a key component in the transmission mechanism of many vehicles and machines. It is a cross coupling that allows power to be transmitted from the engine to the drive shaft while allowing the angle between the connected shafts to change. These products are widely used in cars, trucks, agricultural machinery and heavy industry. The high quality of the cross-brace ensures efficient and quiet operation of the gearbox and minimizes the risk of failure. The bearings are protected from the outside of the fork by rings.
Comparison no:
- GRANIT: 397520019
- GKN U129
Specification
Weight | 0.145 kg |
---|---|
Dimensions | 8.4 × 8.4 × 3 cm |
Bearing diameter | 18 mm |
Width of the crossbar | 47 mm |
Segers included | Not |
Application | Steering column cross member, PTO power take-off |
Seal | Rubber |
Bowl type | Kinked |
